KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory

  • KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory
  • KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory
  • KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory
  • KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory
  • KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory
Место происхождения Лоян, Китай
Фирменное наименование YDPB
Сертификация ISO
Model Number KA035AR0
Количество мин заказа 1pcs
Цена 1$
Packaging Details standard export packaging
Payment Terms Western Union, T/T, L/C

Свяжитесь со мной для бесплатных образцов и купонов.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

скайп: sales10@aixton.com

Если у вас есть какие-либо проблемы, мы предоставляем круглосуточную онлайн-помощь.

x
Подробная информация о продукте
Material GCR15 Precision P6,P5,P4
Structure Custom made available OEM available
Dimension 88.9x101.6x6.35mm
Оставьте сообщение
Характер продукции

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory

Model number- KA035AR0
Thin section ball bearing
Inner ring(mm)-88.9
Outer ring(mm)-101.6
Width(in)- 6.35

Materials- Chrome steel/GCR15/Stainless steel
Precision grade- P6/P5/P4/P2
Lubrication type- Oil
Material(Ball)- Steel ball/Ceramic ball
Number of Row- Single rows
Section Type- Thin section



Description

YDPB is professional on the bearings inlcude Kaydon standard think section bearings ,THK IKO standard crossed roller bearings,INA standard Rotary Table bearings ,and also with many stock ones flexible deep groove ball bearings used for harmonic drive, custom made bearings avaible.



Kaydon thin-section bearings Structure
Open type deep groove ball bearing
Open type angular contact bearing
Open type four point contact bearing
Sealed type deep groove ball bearing
Sealed four point contact ball bearing


Feature
1. compact structure, light weight, low vibration and friction
2. high precision,
3. space and cost saving
4. best quality, long life



Main parameters

  (inch/mm)Dimension  Basic Cap.N

Type

 d D L1 L2 L3 Radial Thrust Weight Interchange
  Cor Cr Coa Ca Kg NTN KAYDON
YDKAA10AG0 1 1.375 1.142 1.236 1.274 1510 670 4310 2000 0.011 KYS010 KAA10AG0
25.4 34.925 29 31.4 32.4
YDKAA15AG0 1.5 1.875 1.642 1.736 1.774 2130 890 6130 3250 0.017 KYS015 KAA15AG0
38.1 47.625 41.7 44.1 45.1
YDKA020AR0 2 2.5 2.186 2.314 2.369 3510 1470 10140 4270 0.045 KYA020 KA020AR0
50.8 63.5 55.5 58.8 60.2
YDKA025AR0 2.5 3 2.686 2.814 2.869 4270 1690 12360 4890 0.054 KYA025 KA025AR0
63.5 76.2 68.2 71.5 72.9
YDKA030AR0 3 3.5 3.186 3.314 3.367 5070 1910 14620 5470 0.064 KYA030 KA030AR0
76.2 88.9 80.9 84.2 85.6
YDKA035AR0 3.5 4 3.386 3.814 3.867 5830 2090 16850 6000 0.077 KYA035 KA035AR0
88.9 101.6 93.6 96.9 98.2
YDKA040AR0 4 4.5 4.186 4.314 4.367 6630 2270 19110 6530 0.086 KYA040 KA040AR0
101.6 114.3 106.3 109.6 110.9
YDKA042AR0 4.25 4.75 4.436 4.564 4.615 7020 2360 20230 6800 0.091 KYA042 KA042AR0
107.95 120.65 112.7 115.9 117.2
YDKA045AR0 4.5 5 4.686 4.814 4.865 7380 2450 21380 7020 0.095 KYA045 KA045AR0
114.3 127 119 122.3 123.6
YDKA047AR0 4.75 5.25 4.936 5.064 5.115 7780 2530 22490 7290 0.1 KYA047 KA047AR0
120.65 133.35 125.4 128.6 129.9
YDKA050AR0 5 5.5 5.186 5.314 5.365 8180 2620 23600 7510 0.104 KYA050 KA050AR0
127 139.7 131.7 135 136.3



Application

Aerospace and defense

Astronomy instrumentation

Fixturing and workholding equipment

Food processing equipment

Glassworking equipment

Index and rotary tables

Packaging equipment

Machine tools

Medical systems and medical devices

Optical scanning equipment

Tire making equipment



Related details

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 0

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 1

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 2

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 3

KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 4



Models list
Open type thin section kaydon deep groove ball bearing:
KA020CP0, KA025CP0, KA030CP0, KA035CP0, KA040CP0, KA042CP0, KA045CP0, KA047CP0, KA050CP0, KA055CP0, KA060CP0, KA065CP0, KA070CP0, KA075CP0, KA080CP0, KA090CP0, KA100CP0, KA110CP0, KA120CP0,

KB020CP0, KB025CP0, KB030CP0, KB035CP0, KB040CP0, KB042CP0, KB045CP0, KB047CP0, KB050CP0, KB055CP0, KB060CP0, KB065CP0, KB070CP0, KB075CP0, KB080CP0, KB090CP0, KB100CP0, KB110CP0, KB120CP0, KB140CP0, KB160CP0, KB180CP0, KB200CP0,

KC040CP0, KC042CP0, KC045CP0, KC047CP0, KC050CP0, KC055CP0, KC060CP0, KC065CP0, KC070CP0, KC075CP0, KC080CP0, KC090CP0, KC100CP0, KC110CP0, KC120CP0, KC140CP0, KC160CP0, KC180CP0, KC200CP0,

KD040CP0, KD042CP0, KD045CP0, KD047CP0, KD050CP0, KD055CP0, KD060CP0, KD065CP0, KD070CP0, KD075CP0, KD080CP0, KD090CP0, KD100CP0, KD110CP0, KD120CP0, KD140CP0, KD160CP0, KD180CP0, KD200CP0,


KF040CP0, KF042CP0, KF045CP0, KF047CP0, KF050CP0, KF055CP0, KF060CP0, KF065CP0, KF070CP0, KF075CP0, KF080CP0, KF090CP0, KF100CP0, KF110CP0, KF120CP0, KF140CP0, KF160CP0, KF180CP0, KF200CP0,

KG040CP0, KG042CP0, KG045CP0, KG047CP0, KG050CP0, KG055CP0, KG060CP0, KG065CP0, KG070CP0, KG075CP0, KG080CP0, KG090CP0, KG100CP0, KG110CP0, KG120CP0, KG140CP0, KG160CP0, KG180CP0, KG200CP0,

Sealed type thin section kaydon deep groove ball bearing:
JA020CP0, JA025CP0, JA030CP0, JA035CP0, JA040CP0, JA042CP0, JA045CP0, JA047CP0, JA050CP0, JA055CP0, JA060CP0, JA065CP0,

JB020CP0, JB025CP0, JB030CP0, JB035CP0, JB040CP0, JB042CP0, JB045CP0, JB047CP0, JB050CP0, JB055CP0, JB060CP0, JB065CP0,

JU040CP0, JU042CP0, JU045CP0, JU047CP0, JU050CP0, JU055CP0, JU060CP0, JU065CP0, JU070CP0, JU075CP0, JU080CP0, JU090CP0, JU100CP0, JU110CP0, JU120CP0,

JG120CP0, JG140CP0, JG160CP0, JG180CP0, JG200CP0,



Transportation available
KA035AR0 Size 88.9x101.6x6.35mm Driving Motors thin section Bearing Kaydon standard thin section bearings factory 5
Payment Terms:
Most of our customers use T/T( 40% in advance, Balance before shippment), Western Union ,Money Gram, for larger amount consider LC, all can be negotiable.


Many other precision bearings series available
1.INA YRT rotary table bearings YRT50.....YRT1200
2.INA YRTS high speed Axial Radial Load Rotary table bearing YRTS200....YRTS460
3.INA YRTM rotary table bearings with AMO angle measuring system to improve the accurancy. YRTM150.....YRTM460
4.INA ZKLDF serie bi-direction thrust angular contact ball bearings ZKLDF100.....ZKLDF460
5.THK (IKO) RB/CRB/CRBC series crossed roller bearings Inner ring rotate bearing id 35mm----1500mm
6.THK RE series crossed roller bearings ,Outer ring rotate id 35mm----1500mm
7.THK RA thin section crossed roller bearing id 100mm---200mm
8.THK SX series crossed roller bearings ,ID 70mm--------500mm
9.THK RU Series integrate inner ring and outer ring ,industrial robots use cross roller bearing RU42---RU445
10.INA XU/XSU series cross roller slewing bearing,XU050077---XU300515,XSU080168---XSU090398
11.IKO CRBH series integrate inner ring and outer ring cross roller bearing CRBH5013------CRBH25025
12.Timken XR/JXR Crossed Tapered Roller Bearings ,used for high speed vertical lathe XR496051---XR,XR678052,XR766051,XR855053,XR882055,XR889058,JXR637050,JXR652050,JXR699050.
13.Kaydon Thin section ball bearings KA,KG,KD series.
14.Ceramic bearings
15.Slewing bearings
16.Custom made bearings
